🚀 Basic Git Tutorial (Windows & Linux)

What is Git?

Simply put, Git is a “Distributed Version Control System.”

• Version Control: It helps you track all the historical changes to your project. Just like having countless save points in a video game, you can return to any “saved” state at any time.
• Distributed: Everyone’s computer has a complete “copy” (repository) of the project. You can work locally (commit, create branches) without needing a constant internet connection.

1. Installing Git

💻 On Windows

1. Visit the official Git website:
   https://git-scm.com/
2. Download the Windows installer.
3. Run the installer. During the installation, keeping the default settings is usually the best choice.
4. The most important step: After installation, you will get a program called Git Bash. Please always use Git Bash. It provides a command-line environment similar to Linux, and all commands in this tutorial will run there.

🐧 On Linux (Ubuntu/Debian example)

Installation on Linux is very simple. Open your terminal and run:

sudo apt update
sudo apt install git

(For other distributions, like Fedora, you can use sudo dnf install git)

2. First-Time Setup: Global Configuration

Before you make your first commit, you need to tell Git who you are. This information will be attached to every commit you make.

On both Windows (open Git Bash) and Linux (open terminal), the commands are identical.

# Set your username
git config --global user.name "Your Name"

# Set your email (Please use the email you registered on GitHub/GitLab with)
git config --global user.email "your.email@example.com"

3. How to Configure a Git Key (SSH Key)

We use SSH keys to achieve a “password-less login.” Once configured, you will no longer need to repeatedly enter your username and password when you clone and push your own projects.

The process is almost identical on Windows (Git Bash) and Linux (terminal).

Step 1: Generate an SSH Key

# Use your email as a label
ssh-keygen -t rsa -b 4096 -C "your.email@example.com"

• After running it, it will ask “Enter file in which to save the key…”
  • Just press Enter to accept the default path (usually ~/.ssh/id_rsa).
• Next, it will ask “Enter passphrase…”
  • It is recommended to press Enter twice (i.e., set no passphrase) for the most convenient pull/push experience.

Step 2: View and Copy Your Public Key

Your “key” is split into two parts: a private key (id_rsa) and a public key (id_rsa.pub). You need to copy the public key (.pub) to the GitHub or GitLab website.

# Display the contents of the public key file
cat ~/.ssh/id_rsa.pub

You will see a long string of text starting with ssh-rsa and ending with your email. Copy this entire string completely.

Step 3: Add it to GitHub/GitLab

1. Log in to your GitHub (or GitLab) account.
2. Go to Settings.
3. Find the SSH and GPG keys menu.
4. Click New SSH key.
5. Title: Fill in anything, for example, “My Windows PC” or “Linux VM”.
6. Key: Paste the public key content you copied in the previous step.
7. Click Add SSH key.

4. Core Git Operations

A. git clone (Clone/Download a Repository)

This is your starting point for joining a project. You download a complete copy of a project from a remote repository (like GitHub) to your local machine.

1. Go to GitHub and find the project you want to clone.
2. Click the green “Code” button.
3. Important: Select the “SSH” tab (not “HTTPS”).
4. Copy the address that starts with git@github.com:....

Then, in your terminal (Git Bash or Linux terminal), run:

# Example address, please replace it with your own
git clone git@github.com:username/project-name.git

# After it finishes, enter the project directory
cd project-name

B. git branch (Branch Management)

Branching is the core magic of Git. You can safely develop new features or fix bugs without affecting the “main line” (usually called main or master).

# 1. See all your current branches (and which one you are on)
git branch

# 2. Create a new branch named "feature-login"
git branch feature-login

# 3. Switch to that new branch (all your changes from now on will be on this branch)
git checkout feature-login

⭐ Common Shortcut (Create and switch immediately):

# This one command = Step 2 + Step 3 above
git checkout -b new-feature-name

C. git push (Pushing Code)

When you have finished your changes locally, you need to “push” these changes back to the remote repository (GitHub) so others can see them.

The complete push workflow (A three-step process):

Let’s assume you have modified files on your feature-login branch.

# 1. Check the status of your files (see what you changed)
git status

# 2. "Stage" your modified files (telling Git you want to commit these)
# ( . means "all modified files")
git add .

# 3. "Commit" your changes and write a "commit message" (explaining what you changed)
git commit -m "Developed the login feature"

The final step: Push!

# Push your local "feature-login" branch to the remote repository "origin"
git push origin feature-login

⭐ Tip: If this is the first time you are pushing this new branch, Git might prompt you to use a more complete command: git push --set-upstream origin feature-login (Just copy and paste what it suggests. This “links” your local branch to the remote branch).

Summary: Windows vs. Linux Differences

As you can see, the core Git commands are exactly the same on Windows (using Git Bash) and Linux.

The only real differences are:

1. Installation Method: Windows uses an .exe installer, while Linux uses a package manager (apt/dnf).
2. Terminal Environment: Linux uses the terminal natively. On Windows, it is highly recommended to use Git Bash for a consistent experience.
3. Line Endings (CRLF vs. LF): This is a hidden pitfall. Windows defaults to CRLF for line breaks, while Linux/macOS use LF. Git can automatically configure this during installation (core.autocrlf), so you usually don’t need to handle it manually.

This basic tutorial should be enough to help you get started.

Data Process

1.after checking the data file,I found that the keyword and location column is NaN.Therefore,I fill “unkown” to replace NaN.

data_train['keyword'] = data_train['keyword'].fillna('uknown_keyword')
data_train['location'] = data_train['location'].fillna('uknown_location')

2.I use Pandas to combine the keyword,location,and text columns of each row in the dataset into a single string,and stores these strings in a list.

corpus = data_train.apply(lambda row:f"keyword:{row['keyword']} | location:{row['location']} | text: {row['text']}",axis=1).tolist()

3.I use BertTokenizer to tokenize and preprocessing the list.

max_len = 0
for sent in corpus:
    # 将文本分词，并添加 `[CLS]` 和 `[SEP]` 符号
    input_ids = tokenizer.encode(sent, add_special_tokens=True)
    max_len = max(max_len, len(input_ids))

print('Max sentence length: ', max_len)

max_len = 0
for sent in corpuss:
    input_ids = tokenizer.encode(sent, add_special_tokens=True)
    max_len = max(max_len, len(input_ids))

print('Max sentence length: ', max_len)

input_ids = []
attention_masks = []

for sent in corpus:
    X_bert = tokenizer.encode_plus(
        sent,
        add_special_tokens = True,
        max_length = 128,
        pad_to_max_length = True,
        return_attention_mask = True,
        return_tensors = 'pt',
    )
    input_ids.append(X_bert['input_ids'])
    attention_masks.append(X_bert['attention_mask'])

input_ids = torch.cat(input_ids,dim=0)
attention_masks = torch.cat(attention_masks,dim=0)
labels = torch.tensor(y, dtype=torch.long)

print('Original: ', corpus[0])
print('Token IDs:', input_ids[0])

input_idss = []
attention_maskss = []

for sent in corpuss:
    encoded_dicts = tokenizer.encode_plus(
                        sent,
                        add_special_tokens = True,
                        max_length = 128,
                        pad_to_max_length = True,
                        return_attention_mask = True,
                        return_tensors = 'pt',
                   )
    input_idss.append(encoded_dicts['input_ids'])
    attention_maskss.append(encoded_dicts['attention_mask'])

input_idss = torch.cat(input_idss, dim=0)
attention_maskss = torch.cat(attention_maskss, dim=0)

4.I use pytorch Dataset to transform the tokenized corpus and corpuss to a dataset used in BERT.

from torch.utils.data import TensorDataset

dataset = TensorDataset(input_ids, attention_masks, labels)
datasets = TensorDataset(input_idss, attention_maskss)#dataset for test doesn't include labels

Model Train

I choose BERT and set

optimizer = AdamW(model.parameters(),
                 lr = 2e-5,
                 eps = 1e-8
                 )

from transformers import get_linear_schedule_with_warmup

epochs = 2

total_steps = len(train_dataloader) * epochs

scheduler = get_linear_schedule_with_warmup(optimizer,
                                           num_warmup_steps = 0,
                                           num_training_steps = total_steps)

Then,I conduct training in small batches

device = torch.device('cuda' if torch.cuda.is_available() else 'cpu')

seed_val = 42

random.seed(seed_val)
np.random.seed(seed_val)
torch.manual_seed(seed_val)
torch.cuda.manual_seed_all(seed_val)

# 存储训练和评估的 loss、准确率、训练时长等统计指标,
training_stats = []

total_t0 = time.time()

for epoch_i in range(0, epochs):
    print("")
    print('======== Epoch {:} / {:} ========'.format(epoch_i + 1, epochs))
    print('Training...')

    # 统计单次 epoch 的训练时间
    t0 = time.time()

    # 重置每次 epoch 的训练总 loss
    total_train_loss = 0

    # 将模型设置为训练模式。这里并不是调用训练接口的意思
    model.train()

    # 训练集小批量迭代
    for step, batch in enumerate(train_dataloader):

        # 每经过40次迭代，就输出进度信息
        if step % 40 == 0 and not step == 0:
            elapsed = format_time(time.time() - t0)
            print('  Batch {:>5,}  of  {:>5,}.    Elapsed: {:}.'.format(step, len(train_dataloader), elapsed))

        b_input_ids = batch[0].to(device)
        b_input_mask = batch[1].to(device)
        b_labels = batch[2].to(device)
        # print(b_input_ids.shape)  # 应为 (batch_size, max_length)
        # print(b_input_mask.shape) # 同上
        # print(b_labels.shape)     # 应为 (batch_size,)

        model.zero_grad()#每次计算梯度前将其清零，因为pytorch梯度是累加的

        #前向
        # loss, logits = model(b_input_ids,
        #                          token_type_ids=None,
        #                          attention_mask=b_input_mask,
        #                          labels=b_labels)

        outputs = model(
            input_ids=b_input_ids,
            attention_mask=b_input_mask,
            labels=b_labels  # 确保传递了 labels
        )

        # 从 outputs 中提取 loss 和 logits
        loss = outputs.loss  # 直接访问 loss 属性
        logits = outputs.logits

        print("模型返回的 loss:", loss.item())

        # 累加 loss
        total_train_loss += loss.item()

        # 反向传播
        loss.backward()

        # 梯度裁剪，避免出现梯度爆炸情况
        torch.nn.utils.clip_grad_norm_(model.parameters(), 1.0)

        # 更新参数
        optimizer.step()

        # 更新学习率
        scheduler.step()

    # 平均训练误差
    avg_train_loss = total_train_loss / len(train_dataloader)

    # 单次 epoch 的训练时长
    training_time = format_time(time.time() - t0)

Model Prediction

I use model.eval to get the prediction result

model.eval()

# Tracking variables
predictions , true_labels = [], []

# 预测
for batch in test_dataloader:
  # 将数据加载到 gpu 中
  batch = tuple(t.to(device) for t in batch)
  b_input_ids, b_input_mask = batch

  # 不需要计算梯度
  with torch.no_grad():
      # 前向传播，获取预测结果
      outputs = model(b_input_ids,attention_mask=b_input_mask)

  logits = outputs.logits

  # 将结果加载到 cpu 中
  batch_logits = logits.detach().cpu().numpy()

  # 存储预测结果和 labels
  predictions.append(batch_logits)

flat_predictions = np.concatenate(predictions, axis=0)
predicted_labels = np.argmax(flat_predictions, axis=1)

Why?

This chanllenge is a classification problem,and BERT has these suitable features:
1.Superior Understanding of Context from Both Directions;
2.Effectiveness in Pre-training and Fine-tuning;What we need to do is to add an untrained neuronal layer at the end, and then train a new model to complete our classification task;
3.Deep Contextual Analysis;
4.Versatility Across Multiple Tasks

Limitation

Long Training Time:I only trained for 2 epochs,but it took 10941.0s.

TO DO

1.Increase the train epochs;
2.Try other models or methods;
3.Add error blog.

Data Process

1.after checking the data file,I found that the keyword and location column is NaN.Therefore,I fill “unkown” to replace NaN.

data_train['keyword'] = data_train['keyword'].fillna('uknown_keyword')
data_train['location'] = data_train['location'].fillna('uknown_location')

2.I use Pandas to combine the keyword,location,and text columns of each row in the dataset into a single string,and stores these strings in a list.

corpus = data_train.apply(lambda row:f"keyword:{row['keyword']} | location:{row['location']} | text: {row['text']}",axis=1).tolist()

3.I use BertTokenizer to tokenize and preprocessing the list.

tokenizer = BertTokenizer.from_pretrained('bert-base-uncased')
X_bert=tokenizer(
    corpus,
    padding=True,
    truncation=True,
    return_tensors='tf'
)

4.I use TensorFlow Dataset to transform the X.Bert to a dataset used in BERT.

dataset = tf.data.Dataset.from_tensor_slices((
    {"input_ids": input_ids, "attention_mask": attention_mask},
    y
)).batch(32)

Model Train

I choose BERT and set

optimizer='adam', loss='binary_crossentropy', metrics=['accuracy']

Why?

This chanllenge is a classification problem,and BERT has these suitable features:
1.Superior Understanding of Context from Both Directions;
2.Effectiveness in Pre-training and Fine-tuning;
3.Deep Contextual Analysis;
4.Versatility Across Multiple Tasks

Limitation

1.Long Training Time:I only trained for 3 epochs,but it took 12719.4s.
2.Not so superior performance:the final score is only 0.57033:Perhaps this is because BERT may not be as effective as traditional machine learning models (e.g., Naive Bayes) or shallow neural networks (e.g., CNNs) for some simple text classification tasks, such as short text classification or binary classification problems, and they also have advantages in terms of computing resources and training time.

TO DO

1.Increase the train epochs;
2.Try other models or methods;
3.Add error blog.

This week focus on paper reading and basic knowledge learning.

First,I summarised the difference of QAT and PTQ.

Quantization-Aware Training (QAT) Core Method

Simulated Quantization During Training,Full Model Fine-Tuning,Quantizing Weights and Activations.

Post-Training Quantization (PTQ) Core Method

Quantization After Training,Static Quantization,Dynamic Quantization.

Here is a chart about comparison of them.

Secondly,I go over knowledge of transfomer,whose note is on the goodnotes.

我总感觉像生活在大海上，受到威胁，然而心中存有巨大的幸福。————加谬

After last week’s exploration,I got more practised.So I have basically done the Deployment on Android,which should be working but got a problem.The problem is every time I open the app containing the Gemma-2-2b,the stimulater got crashed.

I think it’s because the configuration of stimulater is not enough.So there is two ways to solve it:1,use a real phone;2,finetune the model.

I choose the latter.

So the way became so clear,now my work is to use some finetune strategies to make the model works better.

Firstly I tried LoRA.And I will try DV and prunning next week.(no Qutization because the model has already been 8-bit.)(now I found this idea is wrong:d.)

And here’s summary of four ways to optimize LLMs:

Quantization

Quantization minimizes the precision (number after decimal) of model parameters, leading to reduced memory usage and faster computation, which is vital for deploying LLMs on devices with limited resources.

Trade-off: While quantization offers efficiency gains, a potential downside is a slight decrease in model accuracy. The impact on accuracy can vary depending on the specific technique and the task at hand.

Knowledge Distillation

This involves training a smaller “student” model to replicate the performance of a larger “teacher” model. The student model learns to mimic the outputs of the teacher model, achieving similar results with fewer parameters.

Pruning

Pruning involves removing parts of a model (such as neurons or entire layers) that contribute little to the output, effectively reducing the model size and improving computational efficiency without significantly affecting accuracy.

Tuning

Finetuning involves adapting pre-trained models to specific tasks, enhancing their effectiveness without expansive retraining:
Trade-off: It risks overfitting, where the model performs well on training data but poorly on unseen data.

Last Layer Tuning adjusts the final layer of the model, optimizing it for tasks closely related to the original training. The trade off is, that it might not capture complex patterns as that require deeper model adjustments.

Adapter Layer Tuning integrates trainable modules between layers, tailoring the model’s output. As it adds extra parameters to the model, which can increase the computational load.

Prefix Tuning adds tunable parameters at the input sequence start, directing the model’s focus. Trade off is that it requires careful design of the prefix layer to avoid introducing biases.

Low Rank Adaptation (LoRA) employs low-rank matrices for efficient weight adaptation.
potentially impacting the model’s adaptability to highly complex tasks. Trade off is, potentially impacting the model’s adaptability to highly complex tasks.

我觉得神还缺少某些某些东西，只要不存在与之相对的东西。————吕西安

Tried some tutorial about how to deploy a model on Android,but I got lost.Here is the process.

At first,I wanted to change the type of model to TFlite.It is not so easy.

And then,I asked a guy online for some sugggestions.He told me I can use onnx framework and so on,no need for changing the type of model.So I began to learn some something about onnx and tried to use it,finding the framework hard to work.

Eventually,I tried to deploy some tiny models(like CV) following the tutorial online.

Anyways,this week’s exploration is such a chaos.But this week’s exploration gives me a lot of exprience and it’s necessary.

没有生活的的绝望就没有对生活的爱。————加谬

引言：

悠古的回响寥寥，夏娃亚当偷尝禁果的欢欣仍刺激着无数人，
时间流过，我看不见神，
胸中依然感到青春的震荡，
沐浴着新生的水，
“HELLO WORLD”

This blog will contain my code stuff and learning process…and maybe more.

这个博客会包含我的代码相关和学习历程…也许还有别的。
